1. Surge-adaptive Worktop
▸22mm marine-grade plywood substrate (density ≥950kg/m³), surface composite 0.8mm anti-slip wear-resistant coating, friction coefficient μ=0.65 (DNVGL-ST-0358 standard), ensuring documents/equipment stay in place during roll conditions.
▸Desktop-integrated dual-channel cable management system:
•Central embedded 2 waterproof cable holes compliant with IEC 60309 (φ50mm/φ35mm optional)
•Removable cable tray at bottom supporting up to 12 groups of cables classified fixing
•Optional magnetic cable positioners for millimeter-level routing accuracy
2.Dynamic Balance Support System
▸ Three-point hydraulic compensation feet: Built-in MEMS gyroscope monitors ship attitude in real time, adjusts foot height via micro hydraulic cylinder (compensation range ±12cm), maintaining desktop level error ≤0.3° under sea state 5.
▸Leg shock modules: Marine-grade butyl rubber pads (damping coefficient 0.15) filter over 80% low-frequency vibrations, tested to reduce monitor shake by 67%.
1.Intelligent Storage Hub
▸Open grid compartment: Middle black cabinet divided into 3 functional areas:
•Left anti-roll stationery compartment (with silicone anti-slip pad)
•Middle emergency equipment quick-access zone (integrated USB-C waterproof charging port)
•Right magnetic tool board (fixes screwdrivers and other metal tools)
▸Hidden safe (optional): Meets EN1143-1 Security Level 1, supports fingerprint/mechanical dual unlocking, internal moisture-proof silicone pad.
2.Environmental Adaptability Enhancement
▸All metal parts pass 2000-hour salt spray test (ISO 9227), critical joints use 316L stainless steel bolts.
▸Optional antibacterial worktop (nano-silver ions added), inhibiting Escherichia coli >99.8% (ISO 22196).
▸ Size customization: Supports stepless width adjustment 1200-2400mm, depth adjustable in 30mm increments per IMO cabin passage standards.
▸ Functional expansion interfaces:
•M8 threaded mounting holes 预埋 under desk for radar monitor 支架 installation
•Side reserved 24V DC power bus 槽,max. 10A current output
•Optional integrated AIS alarm light & emergency oxygen mask compartment
▸Three-layer protective packaging system:
• Inner layer: Vacuum-sealed aluminum foil bag (with VCI vapor phase rust inhibitor)
•Middle layer: EPS molded cushioning (precisely shaped to desktop)
•Outer layer: Military-grade plywood case (3mm steel corner protectors)
•Passed ISTA 3A transportation test, withstands 2.5m drop impact.
